TW AD-7300 2.0 Version - 7 channel Amp 7X300W@8Ω

  • Sale
  • Regular price $1,575.00


The New Tone Winner AD-7300+ Series Monster Amp - Available Now! With Free Shipping.

www.summithifi.com ( Canada)

www.summithifiusa.com ( USA )

Experience audio brilliance with the Tonewinner AD-7300, a masterpiece that encapsulates cutting-edge technology and timeless design. As a leading name in the audio industry, Tonewinner brings you the AD-7300, a testament to its commitment to delivering superior sound quality and unmatched performance.

The Tonewinner AD-7300 is more than just a device; it's a gateway to an auditory adventure. With meticulous attention to detail, this audio amplifier is designed to transform your listening experience into something extraordinary.

Key Features:

  • Powerful Amplification: With a power output of 300W (8Ω) and 500W+ (4Ω), the AD-7300 delivers robust and dynamic sound that fills any room with clarity and richness.
  • Advanced Technology: Incorporating advanced audio circuitry and high-quality components, this amplifier ensures accurate sound reproduction across the entire frequency spectrum.
  • Elegant Design: The AD-7300's sleek and sophisticated design seamlessly integrates into any living space, adding a touch of elegance to your audio setup.
  • Versatile Connectivity: Equipped with a range of input options, including RCA and balanced XLR inputs, the AD-7300 easily connects to a variety of audio sources for seamless integration.
  • Precise Control: The amplifier provides precise control over your audio, allowing you to fine-tune the sound to match your preferences and the acoustics of your room.

Audio Specifications: 120 Volts Test Results:

  • Topology: Fully discrete, dual differential, high current, short signal path Class A/B - Class "H" power supply.
  • Numbers of Channel: 7 Channels - High-powered single channel modules.
  • Power Output: ( Rated Power; THD <0.1% @ 120V (Tested @ AC 120V) - (AC 240V Will Increase the output wattage and maintain the THD<0.1%.)
  • 300 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; one channel driven.
  • 507 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 4 Ohms; one channel driven.
  • 266 watts RMS/channel; THD<0.1%; 8 Ohms; two channels driven.
  • 434 watts RMS/channel; THD<0.1%; 4 Ohms; two channels driven.
  • 180+ watts RMS/channel; THD<0.1%; 8 Ohms; all Seven channels driven.

Audio Specifications: 240 Volts Test Results:

  • Topology: Fully discrete, dual differential, high current, short signal path Class A/B - Class "H" power supply.
  • Numbers of Channel: 7 Channels - High-powered single channel modules.
  • Power Output: ( Rated Power; THD <0.1% @ 240V (Tested @ AC 240V) - (AC 240V Will Increase the output wattage and maintain the THD<0.1%.)
  • 324 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; one channel driven.
  • 584 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 4 Ohms; one channel driven.
  • 307 watts RMS/channel; THD<0.1%; 8 Ohms; two channels driven.
  • 500 watts RMS/channel; THD<0.1%; 4 Ohms; two channels driven.
  • 200+ watts RMS/channel; THD<0.1%; 8 Ohms; all Seven channels driven.
  • Power Bandwidth (at rated power; 8 Ohm load): 20 Hz to 20 kHz (+ / – 0.1 dB).
  • Broad-Band Frequency Response: 10 Hz to 70 kHz +0/-2 dB.
  • THD + noise: < 0.006%; at 100 watts RMS; 1 kHz; 8 Ohms.
  • Signal to Noise Ratio (8 Ohm load):
  • > 106 dB; ref FTC rated power; unbalanced input (A-weighted).
  • > 91 dB; ref 1 watt; unbalanced input (A-weighted).
  • Minimum Recommended Load Impedance (per channel): 4 Ohms (which equals one 4 Ohm load or two paralleled 8 Ohm loads).
  • Damping Factor (8 Ohm load): > 149.
  • Input Sensitivity (for rated power; 8 Ohm load): 1.5 V.
  • Gain: 28 dB.
  • Maximum Power Consumption: 2056 watts at 120V & 1128W at 240V
  • Power Supply: 110V-240V- 15 Amps-20 Amps Auto Switching Class "H" Power Supply.
  • Material: Aluminum
  • Modules: Separate Heatsinks for individual modules.
  • Color: Black
  • Front Panel: Analogue meter with blue LED lights and Red Needle.
  • G.W: 26.3KGS ( 57.98 Lb)
  • Unit size: 17.48 L X 17.32 W X 7.76 H Inches
  • Package size:22.52 L X 22.52 W X 12.64 H Inches
  • Accessories: 120 Volts - 15 Amp Power cord cable Included
  • Warranty: 2 years warranty

Customer Reviews

Based on 156 reviews
98%
(153)
1%
(2)
1%
(1)
0%
(0)
0%
(0)
R
RDesai3
Can’t beat the TW AD7300

I am very happy with my purchase. It offers excellent performance, build quality and value with a customer service next to none. One email, and I got a phone call to answer my questions.
Sound Quality: exceptional audio quality and performance. All the 7 channels amplify the sound to crisp highs and deep powerful bass. Whether I listen to music or watch movies or watch news, the sound is reproduced with impressive clarity and precision. I can hear instruments that I wouldn’t hear before just with my receiver.
Build Quality & Design: Feels like it ie well built and it is built to last.
Conclusion: Overall, if you are looking for a 7 channel amp with excellent quality, reliability and an attractive price, the TW AD-7300 2.0 is you go to amp. So far very happy and looking forward to continue to enjoy the music among other things.

G
George Georgaklis
Proud Owner of TW AD-7300 Version 2.0

Proud owner of the TW AD-7300 7 Channel AMP. My home theater has been calibrated using Audyssey MultEQ-X. The AMP is performing as advertised and is powering my surround channels as well as the center channel. I also purchased the TW AD-2500 Pro Ver 2.0 to drive my two front Polk L800 speakers. I am totally satisfied with these two Amplifiers. Also a shout out to Amir. You Da Man!

J
J.R.
Tone winner and 7300 question

Now, my unit was purchased through a great guy, whom bought the unit from Aamir. I'm very much impressed with the unit. Runs like a dream ! The question I have is? I'm running it off a 15 amp recepticles. I'm going to upgrade, a dedicated 20 amp line, breaker, audiophile grade recepticles, maybe even a line conditioner at my panel. To the point, can I now use a 20 amp cord, with the unique adapter? Will I get better harmonic distortion? This question is for Aamir or any one with the qualified electrical knowledge. Thanks

M
Mike O
Absolutely beautiful

Best amplifier you can buy at this price in order to get better, you would have to go up at least $10,000 in price even then you’re still not gonna get an amplifier as good looking as this I can’t believe I’m gonna say this, but China should be proud This amplifier is truly a work of art build quality is five stars sound quality is definitely five stars You can’t go wrong with this purchase thank you Amir and Summit hi-fi

M
Mario1925des@gmail.com
Tw ad 7300

Ho my god...total quality amp and so nice looking...dont hesitated to get yourself one...and also very good service from that dealer..
