TW AD-7300 2.0 Version - 7 channel Amp 7X300W@8Ω

  • Sale
  • Regular price $1,575.00


The New Tone Winner AD-7300+ Series Monster Amp - Available Now ! Oh Yessss With Free Shipping.

www.summithifi.com ( Canada )

www.summithifiusa.com ( USA )



Audio Specifications: 120 Volts Test Results:

  • Topology: Fully discrete, dual differential, high current, short signal path Class A/B - Class "H" power supply.
  • Numbers of Channel: 7 Channels - High powered single channel modules.
  • Power Output: ( Rated Power; THD <0.1% @ 120V (Tested @ AC 120V) - (AC 240V Will Increase the output wattage and maintain the THD<0.1%.)
  • 300 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; one channel driven.
  • 507 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 4 Ohms; one channel driven.
  • 266 watts RMS/channel; THD<0.1%; 8 Ohms; two channels driven.
  • 434 watts RMS/channel; THD<0.1%; 4 Ohms; two channels driven.
  • 180 watts RMS/channel; THD<0.1%; 8 Ohms; all Seven channels driven.

Audio Specifications: 240 Volts Test Results:

  • Topology: Fully discrete, dual differential, high current, short signal path Class A/B - Class "H" power supply.
  • Numbers of Channel: 7 Channels - High powered single channel modules.
  • Power Output: ( Rated Power; THD <0.1% @ 240V (Tested @ AC 240V) - (AC 240V Will Increase the output wattage and maintain the THD<0.1%.)
  • 324 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; one channel driven.
  • 584 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 4 Ohms; one channel driven.
  • 307 watts RMS/channel; THD<0.1%; 8 Ohms; two channels driven.
  • 500 watts RMS/channel; THD<0.1%; 4 Ohms; two channels driven.
  • 190+ watts RMS/channel; THD<0.1%; 8 Ohms; all Seven channels driven.


  • Power Bandwidth (at rated power; 8 Ohm load): 20 Hz to 20 kHz (+ / – 0.1 dB).
  • Broad-Band Frequency Response: 10 Hz to 70 kHz +0/-2 dB.
  • THD + noise: < 0.006%; at 100 watts RMS; 1 kHz; 8 Ohms.
  • Signal to Noise Ratio (8 Ohm load):
  • > 106 dB; ref FTC rated power; unbalanced input (A-weighted).
  • > 91 dB; ref 1 watt; unbalanced input (A-weighted).
  • Minimum Recommended Load Impedance (per channel): 4 Ohms (which equals one 4 Ohm load or two paralleled 8 Ohm loads).
  • Damping Factor (8 Ohm load): > 149.
  • Input Sensitivity (for rated power; 8 Ohm load): 1.5 V.
  • Gain: 28 dB.
  • Maximum Power Consumption: 2056 watts at 120V & 1128W at 240V
  • Power Supply: 110V-240V- 15 Amps-20 Amps Auto Switching Class "H"Power Supply.
  • Material: Aluminum
  • Modules: Separate Heatsinks for individual modules.
  • Color: Black
  • Front Panel: Analogue meter with blue LED lights and Red Needle.
  • G.W: 26.3KGS ( 57.98 Lb)
  • Unit size: 17.48 L X 17.32 W X 7.76 H Inches
  • Package size:22.52 L X 22.52 W X 12.64 H Inches
  • Accessories: 120 Volts - 15 Amp Power cord cable Included
  • Warranty: 2 years warranty

Customer Reviews

Based on 110 reviews
97%
(107)
2%
(2)
1%
(1)
0%
(0)
0%
(0)
C
Chad Knorr
Tonewinner AD-7300 2.0

Awesome amp! Nice, clean sound feeding an SVS Ultra speaker ensemble. As usual, excellent service and shipping timeframe from Aamir.

R
R.S.
Great Amp!

I'm in the process of building my dream home entertainment setup. I already have installed 13.1.2 with wall installed speakers and towers for the front and powerful subs. I went for separates and was using old amps with a powerful AV processor. I was not getting the sound that my speakers were capable of. I decided to go for a proper amp for my mains, had a few choices (Monolith, EMOTIVA). Tonewinner was never in the picture considering they were offering similar capabilities at a much lower price. I was reluctant to try, my friend told me that it is still worth a try. I bought this with Aamir's help, shipping was a breeze and got this setup in my rack. I wanted to try this amp at least a few months before I write a review.

I must say this amp sounds so much nicer and my sound stage have improved dramatically! I definitely know that the build quality of this is amazing (for everyone to see), the output is equally amazing.

I would have definitely given 5 stars for this, but I'm getting some occasional speaker thumps. I know the amp may not be the reason for this.

Y
Y S
Awesome, good match with Tannoy XT8F

This is an incredible amplifier, solid build quality, nice aesthetics (VU meter), lot of control with high wattage. This has been a very good match with the Tannoy XT8F for stereo use which otherwise sound good with a tube amp. Aamir is awesome to deal with, he knows his stuff and guides you through setup. If you have any questions just call him. Totally recommend this amplifier and the buying experience with Summit HiFi and Aamir.

M
M.C.
The Magical Combo!: AT-300-16 with two AD-7300 2.0 Amplifiers

Configured in a 9.2.4 setup, these components are delivering on all levels. I have yet to integrate my MiniDSP DIRAC gear because it already sounds amazing… but will soon. Having upgraded from a 7.2 setup, I find myself rewatching movies just because of the awesome sound experience. The AT-300-16 is not perfect operationally, an occasional a reboot is necessary, but it performs very well and is the best value on the market. It allowed me to get into a quality 14-channel system much sooner than I could have otherwise justified ($$$). A special thanks to Amir for his great customer service. I certainly felt like I was in good hands!

P
Paul Coward
TW AD-7300 PA + Version - 7 channel Amp 7× 200W@8ohms is the model #I received

Very well made and well built power amplifier!
I purchased this amplifier for the sole purpose of giving my system a lot more headroom power.
It delivers in every single way, an amplifier of this quality will perform! It performs as Tonewinner has intended. Satisfied with my purchase.
